The AUTO STAC Time Switch JS-30A has big load capacity of 30A.
Program cycle is 24 hours and minimum set-up time is 15 minutes.
It is protected by solid metal housing and easy to install.
| Model | JS-30A |
|---|---|
| Rated Voltage | AC220-240V |
| Rated Frequency | 50/60Hz(Auto) |
| Load Capacity | 30Amp(Resistance) 25Amp(Lamp, Power Factor>0.7) 3000W(Motor, Power Factor>0.5) |
| Program Cycle | 24Hours |
| Minimum Set-up Time |
15Minutes |
| Operation | On-Off 96 times |
| Dimensions (mm) | <BOX> 98(W) x 165(H) x 60(D) |
JS-30A Manual
